A+ Server 2114GT-DNR
Key FEATURES:
1 AIOM
1 TB DDR4 ECC RDIMM
2 2.5" NVMe Hot-Swap- 2 M.2
- 29.9" Depth 2U
- 6 PCIe 4.0 x16
Product specifications
- Supermicro A+ Server 2114GT-DNR – 2U GPU Server – 4x 2.5" NVMe – 2x AIOM – 2600W 1+1 Redundant
- Single Socket Optimized 3rd Generation AMD EPYC™ Processors
- AMD EPYC™ 7203P Processor 8-core 2.80GHz 64MB Cache (120W)
- AMD EPYC™ 7303P Processor 16-core 2.40GHz 64MB Cache (130W)
- AMD EPYC™ 7313P Processor 16-core 3.00GHz 128MB Cache (155W)
- AMD EPYC™ 7443P Processor 24-core 2.85GHz 128MB Cache (200W)
- AMD EPYC™ 7543P Processor 32-core 2.80GHz 256MB Cache (225W)
- AMD EPYC™ 7643P Processor 48-core 2.30GHz 256MB Cache (225W)
- AMD EPYC™ 7663P Processor 56-core 2.00GHz 256MB Cache (240W)
- AMD EPYC™ 7713P Processor 64-core 2.00GHz 256MB Cache (225W)
- 3rd Generation AMD EPYC™ Processors
- AMD EPYC™ 7203 Processor 8-core 2.80GHz 64MB Cache (120W)
- AMD EPYC™ 7303 Processor 16-core 2.40GHz 64MB Cache (130W)
- AMD EPYC™ 7313 Processor 16-core 3.00GHz 128MB Cache (155W)
- AMD EPYC™ 7343 Processor 16-core 3.20GHz 128MB Cache (190W)
- AMD EPYC™ 7413 Processor 24-core 2.65GHz 128MB Cache (180W)
- AMD EPYC™ 7443 Processor 24-core 2.85GHz 128MB Cache (200W)
- AMD EPYC™ 7453 Processor 28-core 2.75GHz 128MB Cache (225W)
- AMD EPYC™ 7513 Processor 32-core 2.60GHz 128MB Cache (200W)
- AMD EPYC™ 7543 Processor 32-core 2.80GHz 256MB Cache (225W)
- AMD EPYC™ 7643 Processor 48-core 2.30GHz 256MB Cache (225W)
- AMD EPYC™ 7663 Processor 56-core 2.00GHz 256MB Cache (240W)
- AMD EPYC™ 7713 Processor 64-core 2.00GHz 256MB Cache (225W)
- AMD EPYC™ 7763 Processor 64-core 2.45GHz 256MB Cache (280W)
- 3rd Generation AMD EPYC™ Processors with AMD 3D V-Cache™ Technology
- AMD EPYC™ 7473X Processor 24-core 2.80GHz 768MB Cache (240W)
- AMD EPYC™ 7573X Processor 32-core 2.80GHz 768MB Cache (280W)
- AMD EPYC™ 7773X Processor 64-core 2.20GHz 768MB Cache (280W)
- Frequency Optimized 3rd Generation AMD EPYC™ Processors
- AMD EPYC™ 72F3 Processor 8-core 3.70GHz 256MB Cache (180W)
- AMD EPYC™ 73F3 Processor 16-core 3.50GHz 256MB Cache (240W)
- AMD EPYC™ 74F3 Processor 24-core 3.20GHz 256MB Cache (240W)
- AMD EPYC™ 75F3 Processor 32-core 2.95GHz 256MB Cache (280W)
- 3200MHz ECC Registered DDR4 DIMMs
- 16GB PC4-25600 3200MHz DDR4 ECC RDIMM
- 32GB PC4-25600 3200MHz DDR4 ECC RDIMM
- 64GB PC4-25600 3200MHz DDR4 ECC RDIMM
- 128GB PC4-25600 3200MHz DDR4 ECC RDIMM
- Micron 7450 PRO M.2 PCIe 4.0 x4 NVMe Solid State Drives
- 480GB Micron 7450 PRO Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (80mm)
- 3.84TB Micron 7450 PRO Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (110mm)
- Micron 7450 MAX M.2 PCIe 4.0 x4 NVMe Solid State Drives
- 400GB Micron 7450 MAX Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (80mm)
- Samsung PM9A3 M.2 PCIe 4.0 x4 NVMe Solid State Drives
- 960GB Samsung PM9A3 Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (110mm)
- 1.92TB Samsung PM9A3 Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (110mm)
- 3.84TB Samsung PM9A3 Series M.2 PCIe 4.0 x4 NVMe Solid State Drive (110mm)
- Solidigm P5620 Series PCIe 4.0 x4 NVMe Solid State Drives (3x DWPD)
- 1.6TB Solidigm SSD D7-P5620 Series U.2 PCIe 4.0 x4 NVMe Solid State Drive
- 3.2TB Solidigm SSD D7-P5620 Series U.2 PCIe 4.0 x4 NVMe Solid State Drive
- 6.4TB Solidigm SSD D7-P5620 Series U.2 PCIe 4.0 x4 NVMe Solid State Drive
- 12.8TB Solidigm SSD D7-P5620 Series U.2 PCIe 4.0 x4 NVMe Solid State Drive
- Broadcom Ethernet Adapters
- Broadcom NetXtreme 1-Gigabit Ethernet Network Adapter – PCIe 2.0 x1 – 2x RJ45
- Broadcom NetXtreme 1-Gigabit Ethernet Network Adapter – PCIe 2.0 x4 – 4x RJ45
- Broadcom NetXtreme 10-Gigabit Ethernet Network Adapter P210TP – PCIe 3.0 x8 – 2x RJ45
- Broadcom NetXtreme 10-Gigabit Ethernet Network Adapter P210P – PCIe 3.0 x8 – 2x SFP+
- Broadcom NetXtreme 25-Gigabit Ethernet Network Adapter P225P – PCIe 3.0 x8 – 2x SFP28
- Broadcom NetXtreme 25-Gigabit Ethernet Network Adapter P425G – PCIe 4.0 x16 – 4x SFP28
- Broadcom NetXtreme 50-Gigabit Ethernet Network Adapter P150P – PCIe 3.0 x8 – 1x QSFP28
- Broadcom NetXtreme 100-Gigabit Ethernet Network Adapter P2100G – PCIe 4.0 x16 – 2x QSFP56
- Broadcom NetXtreme 200-Gigabit Ethernet Network Adapter P1200G – PCIe 4.0 x16 – 1x QSFP56
- Intel X550 Series 10-Gigabit Ethernet Adapters
- Intel® 10-Gigabit Ethernet Converged Network Adapter X550-T2 – PCIe 3.0 x4 – 2x RJ-45
- Intel X710 Series 10-Gigabit Ethernet Adapters
- Intel® 10-Gigabit Ethernet Network Adapter X710-T2L – PCIe 3.0 x8 – 2x RJ45
- Intel® 10-Gigabit Ethernet Network Adapter X710-T4L – PCIe 3.0 x8 – 4x RJ45
- Intel® 10-Gigabit Ethernet Network Adapter X710-DA2 – PCIe 3.0 x8 – 2x SFP+
- Intel® 10-Gigabit Ethernet Network Adapter X710-DA4 – PCIe 3.0 x8 – 4x SFP+
- Intel E810 Series 25/100-Gigabit Ethernet Adapters
- Intel® 25-Gigabit Ethernet Network Adapter E810-XXVDA2 – PCIe 4.0 x8 – 2x SFP28
- Intel® 25-Gigabit Ethernet Network Adapter E810-XXVDA4 – PCIe 4.0 x16 – 4x SFP28
- Intel® 100-Gigabit Ethernet Network Adapter E810-CQDA2 – PCIe 4.0 x16 – 2x QSFP28
- Intel® 100-Gigabit Ethernet Network Adapter E810-2CQDA2 – PCIe 4.0 x16 – 2x QSFP28
- NVIDIA ConnectX-6 Dx Series 100/200-Gigabit Ethernet Adapters
- NVIDIA® ConnectX®-5 EN 100-Gigabit Ethernet Adapter – PCIe 3.0 x16 – 2x QSFP28
- NVIDIA® ConnectX®-6 Dx EN 100-Gigabit Ethernet Adapter – PCIe 4.0 x16 – 2x QSFP56
- NVIDIA® ConnectX®-6 EN 200-Gigabit Ethernet Adapter – PCIe 4.0 x16 – 2x QSFP56
- Intel i350-AM2 Ethernet Adapter – Gigabit Ethernet 2x RJ45 – AIOM OCP 3.0 PCIe 2.1 x4
- Intel i350-AM4 – Gigabit Ethernet 4x SFP – AIOM OCP 3.0 PCIe 2.1 x4
- Intel XL710-BM2 – 10 Gigabit Ethernet 2x SFP+ – AIOM OCP 3.0 PCIe 3.0 x8
- Intel X710-TM4 – 10 Gigabit Ethernet 2x RJ45 & 2x SFP+ – AIOM OCP 3.0 PCIe 3.0 x8
- Broadcom BCM57414 – 2x 25GbE SFP28 – AIOM OCP 3.0 – PCIe 3.0 x8
- Intel E810-CAM1 25GbE – Quad-Port SFP28 – AIOM OCP 3.0 PCIe 4.0 x16
- Trusted Platform Module – TPM 2.0 – Infineon 9670 – Not Provisioned – Vertical
- Thinkmate® Update Manager (OOB Management Package)
- Thinkmate® Server Manager (Datacenter Management Package)
- C19 to C14
- IEC320 C14 to C19 Power Cable – 14AWG – 250V/15A – 4ft / 1.2M (TAA Compliant)
- IEC320 C14 to C19 Power Cable – 14AWG – 250V/15A – 10ft / 3M (TAA Compliant)
- IEC320 C14 to C19 Power Cable – 14AWG – 250V/15A – 6ft / 1.8M (TAA Compliant)
- C19 to C20
- IEC320 C19 to C20 Power Cable, 12AWG, 250V/20A, Black – 6ft
- IEC320 C19 to C20 Power Cable, 12AWG, 250V/20A, Black – 10ft
- C19 to NEMA 5-15P
- IEC320 C19 to NEMA 5-15P Power Cable, 14AWG, 125V/15A, Black – 3ft
- IEC320 C19 to NEMA 5-15P Power Cable, 14AWG, 125V/15A, Black – 6ft (TAA Compliant)
- IEC320 C19 to NEMA 5-15P Power Cable, 14AWG, 125V/15A, Black – 10ft
- C19 to NEMA L6-20P
- IEC320 C19 to NEMA L6-20P Locking Power Cable, 12AWG, 250V/20A, Black – 6ft
- IEC320 C19 to NEMA L6-20P Locking Power Cable, 12AWG, 250V/20A, Black – 12ft
- C19 to C20 (EU)
- IEC320 C19 to C20 Power Cable, 16A, Black, 0.6m, RoHS/REACh
- IEC320 C19 to C20 Power Cable, 16A, Black, 2.0m, RoHS/REACh
- IEC320 C19 to C20 Power Cable, 16A, Black, 4.5m, RoHS/REACh
- C19 to CEE/7 Schuko (EU)
- IEC320 C19 to CEE/7 Schuko Power Cable, 16A, Black, 2.5m, RoHS/REACh
- IEC320 C19 to CEE/7 Schuko Power Cable, 16A, Black, 3.0m, RoHS/REACh
- C19 to BS1363A (UK)
- IEC320 C19 to BS1363A (UK) Power Cable, 13A 240V, Black, 3.0m, RoHS/REACh
- No Windows Operating System
- No Windows Operating System
- Microsoft Windows Server 2025
- Microsoft Windows Server 2025 Standard (16-core) (DSP)
- Microsoft Windows Server 2025 Standard (24-core) (DSP)
- Microsoft Windows Server 2025 Datacenter (16-core) (DSP)
- Microsoft Windows Server 2025 Datacenter (24-core) (DSP)
- CIQ Rocky Linux Support
- CIQ Yearly Premium Support for Rocky Linux, Per Node, On Prem, 1-99 Nodes, 24/7 Web/Email/Slack Assist
- CIQ Yearly Standard Support for Rocky Linux, Per Node, On Prem, 1-99 Nodes, 8-6 Web/Email HD
- Linux Distributions
- Rocky Linux 8.x (64-bit)
- Rocky Linux 9.x (64-bit)
- Debian Linux 12 (64-bit)
- Fedora Linux 40 Server Edition (64-bit)
- openSUSE Leap Linux 15.x (64-bit)
- Ubuntu Linux 22.04 LTS Server Edition (64-bit)
- Ubuntu Linux 24.04 LTS Server Edition (64-bit)
- Red Hat Enterprise Linux Subscriptions
- Red Hat® Enterprise Linux® 8 Server (Self Support) (1 Year)
- Red Hat® Enterprise Linux® 8 Server (Standard) (1 Year)
- Red Hat® Enterprise Linux® 8 Server (Premium) (1 Year)
- Red Hat® Enterprise Linux® 9 Server (Self Support) (1 Year)
- Red Hat® Enterprise Linux® 9 Server (Standard) (1 Year)
- Red Hat® Enterprise Linux® 9 Server (Premium) (1 Year)
- Downgrade Kits for Microsoft Windows Server
- Downgrade Kit – Microsoft Windows Server 2025 Standard to 2022 Standard – COA and DVD Media
- Downgrade Kit – Microsoft Windows Server 2025 Datacenter to 2022 Datacenter – COA and DVD Media
- Device Client Access Licenses for Windows Server 2025
- 1-Device Client Access License (CAL) for Microsoft Windows Server 2025
- 5-Device Client Access License (CAL) for Microsoft Windows Server 2025
- User Client Access Licenses for Windows Server 2025
- 1-User Client Access License (CAL) for Microsoft Windows Server 2025
- 5-User Client Access License (CAL) for Microsoft Windows Server 2025
- Additional Core Licenses for Windows Server 2025 Standard Edition
- Additional 2-core License for Microsoft Windows Server 2025 Standard
- Additional 4-core License for Microsoft Windows Server 2025 Standard
- Additional 16-core License for Microsoft Windows Server 2025 Standard
- Additional Core Licenses for Windows Server 2025 Datacenter Edition
- Additional 2-core License for Microsoft Windows Server 2025 Datacenter
- Additional 4-core License for Microsoft Windows Server 2025 Datacenter
- Additional 16-core License for Microsoft Windows Server 2025 Datacenter
- Thinkmate® ISO 9001 Certified Assembly, Testing, and Quality Control
- 3-Year Warranty Options
- Thinkmate® 3 Year Depot Warranty (Return for Repair)
- Thinkmate® 3 Year Advanced Parts Replacement Warranty (Zone 0)
- Thinkmate® 3 Year Advanced Parts Replacement Warranty (Zone 1)
- Thinkmate® 3 Year Advanced Parts Replacement Warranty (Zone 2)
- Thinkmate® 3 Year Advanced Parts Replacement Warranty and NBD Onsite Service (Zone 0)
- Thinkmate® 3 Year Advanced Parts Replacement Warranty and Onsite Service (Zone 1)
- Thinkmate® 3 Year Advanced Parts Replacement Warranty and Onsite Service (Zone 2)
- 4-Year Warranty Options
- Thinkmate® 4 Year Advanced Parts Replacement Warranty (Zone 0)
- Thinkmate® 4 Year Advanced Parts Replacement Warranty (Zone 1)
- Thinkmate® 4 Year Advanced Parts Replacement Warranty (Zone 2)
- Thinkmate® 4 Year Advanced Parts Replacement Warranty and NBD Onsite Service (Zone 0)
- Thinkmate® 4 Year Advanced Parts Replacement Warranty and Onsite Service (Zone 1)
- Thinkmate® 4 Year Advanced Parts Replacement Warranty and Onsite Service (Zone 2)
- 5-Year Warranty Options
- Thinkmate® 5 Year Advanced Parts Replacement Warranty (Zone 0)
- Thinkmate® 5 Year Advanced Parts Replacement Warranty (Zone 1)
- Thinkmate® 5 Year Advanced Parts Replacement Warranty (Zone 2)
- Thinkmate® 5 Year Advanced Parts Replacement Warranty and NBD Onsite Service (Zone 0)
- Thinkmate® 5 Year Advanced Parts Replacement Warranty and Onsite Service (Zone 1)
- Thinkmate® 5 Year Advanced Parts Replacement Warranty and Onsite Service (Zone 2)
